Tumbler dryer

Garment dyeing

Tumbler dryer

Rotary dryer for ready-made garments, socks and seamless.
Download Brochure

Request brochures

I have read the Privacy Policy and consent to the processing of personal data in accordance with Articles 13-14 of Regulation (EU) 2016/679 GDPR (General Data Protection Regulation) and subsequent amendments.

Technical details

• Available in fixed or tilting execution to facilitate loading and unloading.

• Equipped with reversal of drum rotation direction and electronic systems for controlling cycle times and temperatures.

• Stainless steel heating batteries.

• Stainless steel drum.

• Automatic cool-down at the end of the cycle.

• Possibility of performing finishing with softeners and chemicals.

• Fully automatic systems for loading and unloading are feasible with pass-through model (front loading and unloading in the back).

Technical details


Model
EVF-25EVF-50EVF-75EXR-100EVR-125
Drum depthmm9001065125014551455
Drum capacitymm9001052120012001450
Drum capacityKg255075100125
MotorsKw1,534,55,57
HeatingKg vapore
steam kg
45-50100-130150-180200230-250
Total widthmm9551520173020752075
Total depthmm13101640184021452245
Total heightmm19802120250025102510
Titable
NONONOYESYES
Volumemc0,570,941,4722,41


Model
EVRR-165EVRR-200EVRR-250EVRR-300
Drum diametermm1455175017501750
Drum depthmm2000165020502450
Drum capacityKg165200250300
MotorsKw9,5121621
Heatingkg vapore
steam kg
250-300350-400450-500550-600

Total width

mm2075238023802380
Total depthmm2795233527353135
Total heightmm2520296029602960
Titable
YES
in front-behind
YES
in front-behind
YES
in front-behind
YES
in front-behind
Volumemc3,333,974,935,89
